1 HP, Single-Phase Motor with dual-voltage operation: 115V or 230V
TENV (Totally Enclosed, Non-Ventilated) housing keeps debris and moisture out
Marine-grade stainless steel housing with aluminum end caps
Operates at 1725 RPM with a 56C C-Face flange mount
Works with any known drum switch or boat lift remote
Heavy-duty gasketed capacitor housing and wire access plate
UL Recognized • NEMA Certified • Class F insulation • IP54 protection
Removable drain holes at 12:00, 3:00, 6:00, and 9:00 positions
Draws 15.6 amps at 115V or 7.8 amps at 230V
Built to operate up to 40°C ambient temperature
Comes with detailed wiring diagrams for Elite, Salzer, and Bremas drum switch
-
BH-USA A‑Drive and E‑Drive
Golden Boat Lifts SEA‑Drive
AMS E‑Drive and Hefty Hoist Series
Hi‑Tide, Neptune, Tide Tamer, and Hurricane boat lifts
Deco Direct Drive and Gearbox models
Compatible with GEM, Galaxy, TED, and Elite remotes
-
In stock now. Ships within 1–2 business days from our Tampa Bay location.
-
1 year manufacturer's warranty
You have 30 days from the date of purchase to return the unopened or unused merchandise. To initiate a return, please call our office for arrangements.
