Key Features
Double worm reduction
Fully enclosed direct-drive design
No exposed belts, pulleys or gears
Internally lubricated gear system
Fits 2-3/8” OD (2” ID) drive pipes
Direct C-Face motor mounting
Up to 9,000 lb. maximum rating
Cover cap included
What Is a Double Worm Reducer?
A double worm reducer uses two stages of gear reduction to reduce motor speed while increasing the torque delivered to the boat lift drive system.
The E-Drive keeps both reduction stages enclosed and internally lubricated, eliminating the exposed belt and pulley arrangement found on traditional flat-plate hoists.
Product Specifications
600:1
Gear Ratio:
Input RPM:
1725 RPM
Output RPM:
GEM Remotes/7240
2.87 RPM
GEM Remotes manufactured after March 2007
9,000 lbs.
Up to 300 feet
Up to 16
Yes
Yes
372 MHz
Up, Down, Stop
2 CR2032 Batteries
Max. Rating:
Drive Pipe:
2-3/8” OD (2” ID)
C-Face
Motor Mount:
Material:
Steel
Specially Blended
Lubricant:
LxWxH:
15.5” x 3.75” x 19.5”
Input Chamber Capacity:
12 oz.
Output Chamber Capacity:
64 oz.
Frequently Asked Questions
No. The E-Drive is a direct-drive system with no exposed belts or pulleys.
1
Does it use belts or pulleys?
Yes. Both stages of reduction are internally lubricated and sealed.
2
Is the gearbox lubricated?
What motor does the E-Drive use?
3
It is designed for direct mounting to a C-Face electric motor.
Can this replace a traditional flat-plate boat hoist?
4
It may be used as an alternative to traditional belt-and-pulley drive systems, but mounting, drive pipe and motor requirements should be verified before ordering.
