Aqua Marine Supply Boat Lift Motor: Painted 56 Frame

from $379.00

The Aqua Marine Supply 56 Frame Painted Boat Lift Motor is designed for belt-driven flat-plate boat lift hoists. Its rigid-base configuration mounts directly to compatible gear plates and uses a motor pulley and drive belt to operate the hoist.

Available in 3/4 HP and 1 HP, these AC single-phase reversible motors feature a painted steel housing, TENV enclosure, and 5/8" keyed shaft. Aqua Marine Supply specifies both motors for use with Flat Plate and EBD hoist systems.

Shaft key is included.

Horsepower:

Shaft key is included.

QUALITY GUARANTEE

FAST SHIPPING

Genuine parts for long-lasting performance

Orders ship same or next business day

Trusted boat lift service throughout Tampa Bay

We’re here to help with any questions

TRUSTED SERVICE

EXPERT SUPPORT

Key Features

Designed for flat-plate and EBD boat lift hoists

Rigid-base design mounts to compatible gear plates

TENV enclosure helps protect internal motor components

Reversible operation for raising and lowering the boat lift

Available in 3/4 HP and 1 HP options

Designed for Flat-Plate Boat Lift Hoists

These Aqua Marine Supply motors use a rigid mounting base for installation on compatible flat-plate gear assemblies. The motor drives the hoist through a motor pulley and drive belt, rather than mounting directly to the gearbox like a C-Face motor.

Both the 3/4 HP and 1 HP models have a 5/8" keyed shaft, making them suitable for the corresponding motor pulley used on the hoist system. Aqua Marine Supply specifically lists both models for Flat Plate and EBD applications.

TENV stands for Totally Enclosed Non-Ventilated. The enclosed construction helps protect the motor's internal components from the surrounding environment without relying on outside air flowing through the motor for cooling.

This type of enclosure is well suited for boat lift applications where motors are regularly exposed to humid waterfront conditions.

What Does TENV Mean?

GEM Remotes manufactured after March 2007

GEM Remotes/7240

Up to 300 feet

Up to 16

Yes

372 MHz

Up, Down, Stop

2 CR2032 Batteries

Choosing Between 3/4 HP and 1 HP

The correct motor depends on the gear plate, lift configuration, number of motors, and rated capacity of the boat lift.

If you're replacing an existing motor, start by checking the motor nameplate and matching the horsepower, voltage, frame/mounting configuration, and shaft size.

Do not increase motor horsepower solely to increase the lifting capacity of the boat lift. The hoist, structure, cables, electrical system, and other components must all be rated for the intended load.

Choose Your Horsepower

Select the horsepower that matches your boat lift and hoist requirements.

Details

¾ HP

1 HP

Frame

Mounting

Rigid Base

Enclosure

TENV

Housing

Painted Steel

Speed

1725 RPM

AC,
Single Phase

Motor Type

AC,
Single Phase

Voltage

115 / 230V

Amperage

12.2 / 6.1A

13.8 / 6.9A

Frequency

60 Hz

Service Factor

1.25

1.0

Duty Cycle

15 Minute

Shaft Diameter

5/8”

Shaft Key Included

Yes

Key Size

3/16”

Important: Select motor horsepower based on your boat lift and hoist requirements. If you're unsure which motor is right for your lift, please contact us before ordering.
